Name: S&P TD 160-100 N Intermittent Inline Fan
SKU: 00146
Price: 110.0 EUR
Availability: InStock

View our recommended ventilation products (trade enquiries welcomed)

S&P TD 160-100 N Intermittent Inline Fan

Store / Extractor Fans Manufactures & Brands

€110.00

Price incl. VAT (23%) €20.57

In stock

Product Details

Product Description

The S&P TD 160-100 N is a very quiet running inline fan with a choice of two flow rates of flow rates of 50 litres per second and 38 litres per second . Can be used in 100mm solid ducting up to 6 meters. This fan can be connected to a separate PIR sensor with a overrun timer adjustable from 1 to 30 minutes which is a requirement for most bathroom (see accessories).

This domestic axial in-line fan is designed to solve ventilation problems for ducted systems. The motors are assembled on silent elastic blocks and fitted with ball bearings for enhanced working life. The high extraction rate of the fan is 180 cubic meters in free air which makes the fan perfect for bathrooms where the ducting has to travel over another room to an exit point.

Flexible location enables Silent TD 160/100 fan to be connected to any point on the ventilation duct; at the beginning, in-between or at the end, without the loss of any performance.

Key features

IP44 Rated
Choice of two flow rates of 50 & 38 litres per second
Quiet running fan, sound level of 24 and 21 dB(A)
Built-in mounting frame with quick-release motor clips
Not suitable for speed control
2 Year Warranty
Free delivery

Download Product Brochure
